UML 2 Toolkit

Gain the skills to effectively plan software applications and systems using the latest version of UML UML 2 represents a significant update to the UML specification, from providing more robust mechanisms for modeling workflow and actions to making the modeling language more executable. Now in its second edition, this bestselling book provides you with all the tools you'll need for effective modeling with UML 2. The authors get you up to speed by presenting an overview of UML and its main features. You'll then learn how to apply UML to produce effective diagrams as you progress through more advanced topics such as use-case diagrams, classes and their relationships, dynamic…
